Solis S6-EH1P8K-L-PLUS 8kW Single Phase Hybrid Solar Inverter

Description

Solis S6-EH1P8K-L-PLUS 8kW Single Phase Hybrid Solar Inverter

Designed for demanding luxury villas, large multi-family compounds, private healthcare centers, commercial workspaces, and institutions requiring substantial single-phase continuous power, low utility bills, and battery-backed resilience over standard single-phase 220V/230V grids, the Solis S6-EH1P8K-L-PLUS is the flagship 8kW heavyweight in Ginlong Solis’s 6th generation (S6) hybrid energy storage family. It dynamically balances power flows among high-output solar arrays, energy storage battery banks, the utility grid, and on-site auxiliary diesel or petrol generators.

The solar DC input architecture features Dual Independent Maximum Power Point Trackers (MPPT) with 4 DC string inputs (2 strings per MPPT). Supporting up to 12.8 kW of usable PV input (and accommodating up to 16.0 kW recommended PV array oversizing), the MPPT stages operate across a wide voltage window of 90V to 435V (start-up at 90V). With an upgraded continuous DC input current capacity of 32A per MPPT (40A short-circuit current), it eliminates current clipping when paired with high-power 550W+ to 700W+ bifacial solar modules. Dual MPPT channels allow system engineers to split strings across multiple roof pitches or compass orientations without mismatch losses.

The energy storage subsystem operates on an accessible low-voltage 40V to 60V DC architecture (nominal 48V/51.2V) compatible with leading Lithium Iron Phosphate (LiFePO4) battery modules and deep-cycle Lead-Acid banks. Engineered with a high-capacity 190A maximum charge and discharge current, it can rapidly replenish large battery banks during peak sunlight or low-cost grid hours. When grid failure occurs, the inverter switches to backup mode via its integrated automatic transfer switch in less than 4 milliseconds (<4ms)—faster than standard off-grid inverters—preventing computer servers, workstation setups, security DVRs, and sensitive medical instruments from rebooting. A 10-second 200% surge envelope (16 kVA) absorbs high inductive motor startup spikes from heavy submersible pumps, commercial refrigeration, and multiple inverter air conditioners.

Constructed inside an all-weather IP66-certified weather-sealed enclosure, the inverter employs intelligent redundant fan cooling to ensure reliable thermal dissipation under heavy ambient loads and operating temperatures from –40 °C to +60 °C. Comprehensive safety features include integrated ground fault monitoring, DC reverse-polarity protection, anti-islanding protection, and optional integrated AFCI 2.0 DC arc-fault circuit interruption. Remote fleet monitoring is accessible via SolisCloud over CAN, RS485, and plug-and-play Wi-Fi/GPRS modules, complemented by a local 7.0-inch LCD display and built-in Bluetooth for offline configuration.

Product Pricing & Availability

The retail price for the Solis S6-EH1P8K-L-PLUS 8kW Single Phase Hybrid Solar Inverter in Bangladesh typically ranges between 165,000৳ and 175,000৳ (with current authorized promotional cash pricing around 165,000৳ to 170,000৳ against regular showroom list prices reaching 189,000৳ to 220,000৳).

Turnkey residential and commercial hybrid solar packages, 48V / 51.2V LiFePO4 battery storage banks (Pylontech, Dyness, LVTOPSUN), Tier-1 solar modules, AC/DC distribution boards, and professional installation services are fulfilled directly through International Office Solution.
