| Key Features | |
|---|---|
| Data Rate | WiFi 7 (802.11be) (2.4GHz): up to 688 Mbps WiFi 7 (802.11be) (5GHz): up to 5764 Mbps |
| Antenna | External fixed antenna x 6 |
| Button | WPS Button, Reset Button, Power Button |
| Frequency | 2.4 GHz 5 GHz |
| Wireless | MU-MIMO UTF-8 SSID WiFi MAC Address Filter • Maximum MAC Filters : 64 Wireless Scheduler Airtime Fairness RADIUS Client Universal Beamforming |
| Interface | • HFS+ • NTFS • vFAT • ext2 • ext3 • ext4 • FAT32 Safely Remove Disk AiCloud Download Master AiDisk Media Server Time Machine Samba Server FTP Server Shared Folder Privileges |
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) WiFi 7 (802.11be) IPv4 IPv6 |
| Encryption | AiProtection VPN WPA/WPA2/WPA3 Personal WPA/WPA2/WPA3 Enterprise Open System & OWE WPS Let's Encrypt DNS-over-TLS SSH Security Scan Firewall • Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64 |
| Ports | 1 x 2.5GbE for WAN 3 x 2.5GbE for LAN 1 x USB 3.2 Gen1 |
| Others | Processor: 1.5GHz Quad-core Processor Memory: 256 MB Flash and 1 GB RAM Boosts Speed: OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 4096-QAM high data rate 20/40/80/160 MHz bandwidth AiMesh: AiMesh • Primary AiMesh Router • AiMesh Node Game: Game Boost / Acceleration Gear Accelerator OpenNAT (Game Profile) Gaming Port Parental Control: "Allow you to block access to unwanted websites and apps." Web & Apps Filters Time Scheduling Safe Browsing Customized Internet Schedule • Maximum Parental Control Profile : 64 • Maximum Parental Control Content Cilter Rule : 64 Guest Network: "The Guest Network provides Internet connection for guests but restricts access to your local network." Support Guest Network • Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 3 Guest Network Connection Time Limit Guest Network Encryption : Open system, WPA/WPA2/WPA3 Personal AiProtection: AiProtection Pro • Router Security Assessment • Malicious Site Blocking • Two-Way IPS • Infected Device Prevention and Blocking VPN: Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion Support Surfshark Support Nord VPN Traffic Control: Adaptive QoS • Bandwidth Monitor • Bandwidth Limiter -- Maximum Bandwidth Limiter Rule : 32 Traditional QoS Traffic Monitor • Real-time Traffic Monitor • Wired Traffic Monitor • Wireless Traffic Monitor Traffic Analyzer • Traffic Analysis Period : Daily, Weekly, Monthly • Website History WAN: Internet Connection Type : • PPPoE • PPTP • L2TP • Automatic IP • Static IP • IPSec Dual WAN 3G / 4G LTE dongle Port forwarding • Maximum Port Forwarding Rule : 64 Port triggering • Maximum Port Triggering Rule : 32 DMZ DDNS • PPTP Pass-Through • L2TP Pass-Through • IPSec Pass-Through • RTSP Pass-Through • H.323 Pass-Through • SIP Pass-Through • PPPoE Relay LAN: DHCP Server IPTV Manually Assign IP Address • Maximum Manually Assign IP Address Rule : 64 Wake on LAN (WOL) Administration: Configuration Backup and Restore Diagnosis tools Feedback System System Log New Device Connect Notification Login Captcha Connection Diagnosis Auto Firmware Update |
| Power Source | |
| Power Mode | AC Input : 110V~240V(50~60Hz) DC Output : 12 V with max. 2.5 A current |
| Physical Dimension | |
| Dimension | 304 x 174 x 214 mm |
| Weight | 772 g |
| Color | Black |
| Manufacturer warranty | |
| Warranty | 2 Year |
